69
HCD-VM330AV
8-3. CHASSIS SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 4-232-787-01 HOLDER, LED
102 1-680-795-21 CD LED BOARD
103 4-231-311-01 TABLE (60)
104 3-703-136-11 SCREW, TAPPING
0 105 1-823-002-11 CORD, POWER
106 A-4726-732-A MAIN AMP BOARD, COMPLETE
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
107 1-680-803-31 POWER BOARD
108 3-703-244-00 BUSHING (2104), CORD
109 1-683-049-11 FUSE BOARD
111 1-680-804-31 VOL SEL BOARD
112 3-701-748-00 CLAMP
0 T901 1-437-290-11 TRANSFORMER, POWER
104
105
106
108
112
107
T901
111
103
102
109
101
#1
#1
#1
#1
not supplied
not supplied
not supplied
not
supplied
not
supplied
CDM64-K1BD44A
not supplied
not
supplied
#1
#1
#1
#1
#1
#1
#1
#1
#6
#1
#1
#1
#1
#1
#1
#1
#1
#1
#5
#5
#3
