HCD-VM330AV
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
8-5. BASE UNIT SECTION
(BU-30ABD61A)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
601 A-4725-561-A BD BOARD, COMPLETE
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0 603 A-4735-189-A BU-30 (61) ASSY
604 4-234-824-01 RUBBER, VIBRATION PROOF
