72
HCD-VM330AV
SECTION 9
ELECTRICAL PARTS LISTBD
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4725-561-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C102 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C110 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-126-607-11 ELECT CHIP 47uF 20% 4V
C113 1-126-209-11 ELECT CHIP 100uF 20% 4V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C117 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C118 1-164-346-11 CERAMIC CHIP 1uF 16V
C119 1-164-346-11 CERAMIC CHIP 1uF 16V
C120 1-126-607-11 ELECT CHIP 47uF 20% 4V
C151 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C153 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C163 1-117-681-11 ELECT CHIP 100uF 20% 16V
C164 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C165 1-124-779-00 ELECT CHIP 10uF 20% 16V
C166 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C182 1-128-995-21 ELECT CHIP 100uF 20% 10V
C201 1-126-246-11 ELECT CHIP 220uF 20% 4V
C202 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C205 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C212 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C221 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C222 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C224 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C226 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C227 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C228 1-164-346-11 CERAMIC CHIP 1uF 16V
C229 1-163-038-00 CERAMIC CHIP 0.1uF 25V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C231 1-128-995-21 ELECT CHIP 100uF 20% 10V
C234 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C235 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C236 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
< CONNECTOR >
CN101 1-784-875-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CN102 1-794-424-11 CONNECTOR, FCC/FPC 16P
< DIODE >
D101 8-719-056-77 DIODE UDZ-TE-17-3.9B
< FERRITE BEAD >
FB101 1-500-445-21 FERRITE 0uH
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC102 8-759-713-70 IC AN41020A
IC103 8-752-089-74 IC CXA2581N-T4
IC106 8-759-834-29 IC MC74VHC1G04DFT1
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
Q103 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R102 1-216-077-00 RES-CHIP 15K 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-077-00 RES-CHIP 15K 5% 1/10W
R105 1-216-049-11 RES-CHIP 1K 5% 1/10W
R111 1-216-099-00 METAL CHIP 120K 5% 1/10W
R113 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R114 1-216-102-00 RES-CHIP 160K 5% 1/10W
R115 1-216-085-00 RES-CHIP 33K 5% 1/10W
R116 1-216-085-00 RES-CHIP 33K 5% 1/10W
R118 1-216-295-11 SHORT 0
R120 1-216-099-00 METAL CHIP 120K 5% 1/10W
R122 1-216-097-11 RES-CHIP 100K 5% 1/10W
R123 1-216-001-00 METAL CHIP 10 5% 1/10W
R124 1-216-797-11 METAL CHIP 10 5% 1/16W
R125 1-216-085-00 RES-CHIP 33K 5% 1/10W
R126 1-216-085-00 RES-CHIP 33K 5% 1/10W
• Abbreviation
AUS : Australian model
CND : Canadian model
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
