HT-CT770
SECTION 7
ELECTRICAL PARTS LIST
A-1979-510-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
* C801 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C805 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C820 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C821 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C822 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C823 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C824 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
C825 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
* C826 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C827 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C828 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C829 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C830 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C831 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C832 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C833 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
C834 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C835 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C836 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
< CONNECTOR >
CN801 1-816-650-51 FFC/CONNECTOR, FPC (LIF) 24P
CN802 1-816-655-51 FFC/CONNECTOR, FPC (LIF) 8P
CN803 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN804 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< DIODE >
D801 6-502-395-01 LED SL-194S-WS-SD-T (LAMP (WHITE))
D802 6-503-196-01 LED CL-194S-HB8SP-SD-T (LAMP (BLUE))
D803 6-502-961-01 DIODE DA2J10100L
D808 6-500-400-01 DIODE BAV99-215
D809 6-500-400-01 DIODE BAV99-215
D810 6-502-241-01 DIODE KDZTR2.0B
D811 6-503-040-01 DIODE DZ2J300M0L
D812 6-503-737-01 DIODE CES520
< IC >
IC802 6-600-767-01 IC PNA4823M02S0
IC806 6-719-198-01 IC MM3411A33URE
< COIL >
L001 1-481-524-11 INDUCTOR 10uH
< FLUORESCENT INDICATOR TUBE >
ND001 1-483-520-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q803 6-552-941-01 TRANSISTOR LTC023JUBFS8TL
Q804 6-552-941-01 TRANSISTOR LTC023JUBFS8TL
Q805 6-553-291-01 TRANSISTOR BC817DPN
< RESISTOR >
R801 1-216-805-11 METAL CHIP 47 5% 1/10W
R802 1-216-805-11 METAL CHIP 47 5% 1/10W
R803 1-216-805-11 METAL CHIP 47 5% 1/10W
R804 1-216-805-11 METAL CHIP 47 5% 1/10W
R805 1-216-805-11 METAL CHIP 47 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R810 1-216-809-11 METAL CHIP 100 5% 1/10W
R811 1-216-809-11 METAL CHIP 100 5% 1/10W
R812 1-216-809-11 METAL CHIP 100 5% 1/10W
R813 1-216-805-11 METAL CHIP 47 5% 1/10W
R814 1-216-805-11 METAL CHIP 47 5% 1/10W
R825 1-216-809-11 METAL CHIP 100 5% 1/10W
R826 1-216-839-11 METAL CHIP 33K 5% 1/10W
R827 1-216-797-11 METAL CHIP 10 5% 1/10W
R828 1-216-797-11 METAL CHIP 10 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canadian model
EA : Saudi Arabia model
SP : Singapore model
TW : Taiwan model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
