HT-CT770
REVISION HISTORY
Ver. Date Description of Revision
1.0 2014.02 New
1.1 2014.06 Addition of Chinese, Saudi Arabia, Singapore and Taiwan models
Deletion of CUSHION (B) (2 pieces)
(SMR-13060)
How to search for a contact point of signal lines or the like in DIAGRAMS SECTION
If a contact point of a BLOCK DIAGRAM, PRINTED WIRING BOARD or SCHEMATIC DIAGRAM is shown in a different page, use
the PDF fi le search function to fi nd one.
e.g.) If a contact point is shown as
, follow the procedure below.
Procedure:
1. Press the [F] key while pressing the [Ctrl] key.
2. Input “>001Z” in the search box and press the [Enter] key.
3. The relevant part (page), where the contact point is shown, appears.
Note: If you still see the original page, press the [Enter] key again.
