Sony SNC-CH110 User Manual

Operating the Camera
Logging in to the System
20
Logging in to the System
Logging in as a user
1 Start the Web browser on your computer and type
the IP address of the camera you want to monitor.
The viewer is displayed.
Display sample:
Three types of viewer are available: ActiveX
viewer, Plug-in free viewer and custom homepage.
By default, ActiveX viewer is displayed. To switch
the viewer, make changes to the Viewer menu
(page 76).
Note
If the main viewer does not start correctly, the security
level of the Internet Explorer may be set to higher than
Medium. See “To display the viewer correctly” on
page 16 and check the security level.
About Viewers
You can use the following viewers.
ActiveX viewer
This viewer can monitor the camera image in any of the
JPEG, MPEG4 and H.264 video codecs.
You must install this viewer when you access the main
viewer for the first time.
When you display the main viewer of the
camera for the first time
When you access the network camera using ActiveX
viewer for the first time, the Security Warning appears.
Click Ye s and install ActiveX Control. You can use all
the functions of the viewer with ActiveX Control.
Plug-in free viewer
This viewer allows the user to select from three image
display methods: JPEG, JPEG/Flash or ActiveX viewer.
JPEG method: JPEG images will be displayed in
sequence.
JPEG/Flash method: JPEG images will be displayed in
sequence. Adobe Flash is required to display the image.
ActiveX viewer method: The image can be viewed when
the image display is set to JPEG, MPEG4 or H.264.
Notes
• If Automatic configuration is enabled in the Local
Area Network (LAN) Settings of Internet Explorer,
the camera image may not be displayed. In that case,
disable Automatic configuration and set the Proxy
server manually. For the setting of the Proxy server,
consult your network administrator.
• When you install ActiveX Control, you should be
logged in to the computer as the Administrator.
Tip
Every page of this software is optimized for Internet
Explorer in Medium font.

Sony SNC-CH110 Specifications

General

Maximum resolution	1280 x 960 pixels
Video formats supported	H.264
Analog signal format system	NTSC, PAL
White balance	Auto, Manual
Camera shutter speed	1/2 - 1/10000 s
Minimum illumination	5 lx
Sensor type	CMOS
Optical sensor size	1/3.8 \
Video motion detection	Yes
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client), SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
Dimensions (WxDxH)	44 x 93 x 44 mm
Networking features	EEE802.1X
Compatible operating systems	WindowsXP, WindowsVista (32bit), Windows7 (32bit)
Power source type	PoE
Power consumption (typical)	2.4 W
Minimum RAM	1024 MB
Compatible memory cards	SD
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Certification	UL2044, FCC 15B Class B, IC Class B, IEC60950-1, EN55022(B)+EN55024+EN50130-4, VCCI Class B, C-Tick Class B

Weight and Dimensions

Length	93 mm
Weight	100 g
Diameter	44 mm
