Administrating the Camera

Sending Images to FTP Server — FTP Client Menu

Remote path

Type the path to the destination using up to 64

characters.

Image file name

Type the file name you want to assign to the images

when sending to the FTP server. You can use up to 10

alphanumeric characters, – (hyphen) and _ (underscore)

for naming.

Suffix

Select a suffix to be added to the file name.

Date & time: The date & time suffix is added to the

image file name.

The date/time suffix consists of the year (2 digits),

month (2 digits), date (2 digits), hour (2 digits),

minute (2 digits) and second (2 digits), and

sequential number (2 digits), thus adding a 14-digit

number to the image file name.

Sequence number: A sequential number of 10 digits

between 0000000001 and 4294967295 and a

sequential 2-digit number are added to the image file

name.

Tip

A sequential number added to Date & time and

Sequence number is used to identify individual files

created with consecutive alarm events.

Sequence number clear

Click Clear to reset the Sequence number suffix to 1.

Alarm

Select the alarm to be linked with the file to be

forwarded to the FTP server.

Sensor input 1: The external sensor that is connected to

sensor input of the camera I/O port.

Camera tampering detection: An alarm that is

triggered if the camera detects tampering, such as

direction shifting or spray.

Motion detection: The alarm detected by the motion

detection function.

Click Detection, and the Motion detection menu is

displayed to allow you to set the motion detection

function (page 73).

Note

When a preset position is set in the menu of Preset

Position-Alarm linked position, the alarm is invalid if

the camera is moved to a preset position.

Effective period

Set the period during which alarm detection is effective.

Always: Alarm detection is always effective.

Schedule: You can specify the period during which

alarm detection is effective.

Click Schedule and the menu for the effective period

is displayed. (“Setting the Schedule — Schedule

Menu” on page 72)

OK/Cancel

See “Buttons common to every menu” on page 32.

Periodical sending Tab — Setting

the periodical FTP client activity

You can set to send image files (JPEG files) to an FTP

server periodically.

Note

When more than two of the following settings are

activated, the camera only creates two still images at the

same time. A third still image cannot be created unless

one of the previous two still images is sent.

e-Mail (SMTP) menu

– Alarm sending tab Alarm sending (when file

attachment is set to On).

– Periodical sending Periodical sending

FTP client menu

– Alarm sending tab Alarm sending

– Periodical sending Periodical sending

Trigger menu

– Mail (SMTP)

– FTP Client

Periodical sending

Select On when you want to use periodical sending.

Remote path

Type the remote path using up to 64 characters.
