Administrating the Camera
Setting the SSL function — SSL Menu
53
To remove an installed CA
certificate
1
In Internet Explorer, click in the order Tool s,
Internet options, Content tab and Certificates.
The Certificates dialog appears.
2
Select the certificate you want to remove.
The CA certificate is usually stored in Trusted
Root Certification Authorities.
3
Click Remove.
Do you want to delete the certificate appears,
requesting confirmation.
4
Click Ye s.
The certificate will be removed.
There may be a case that a certificate cannot be
removed by the steps above due to the type of
certificate. Check the installation condition and
remove it following the steps below.
Note
You need to log in as Administrator to perform these
steps.
1
Open Run... of the Windows menu, then enter mmc
and click OK.
2
Select File in the Console 1 window and Add/
Remove Snap-in... (when Windows XP
Professional is used)
Add/Remove Snap-in... dialog appears.
3
Click Add to display Add Stand-alone Snap-in
dialog.
You need to follow this step if using Windows XP
Professional.
4
Select Certificates from the list, then click Add.
Certificate Snap-in is displayed.
5
Select Computer account as the certificate
administrated in this Snap-in, then click Next.
6
Select Local Computer as the computer
administrated in this Snap-in, then click Finish.
7
Close Add Standalone Snap-in (for Windows XP
Professional only) and Add/Remove Snap-in...
dialogs.
The items for administrating Certificates appears
in the Console Route window.
Confirm the relevant certificate, then remove it.

Table of Contents

Other manuals for Sony SNC-CH110

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony SNC-CH110 and is the answer not in the manual?

Sony SNC-CH110 Specifications

General IconGeneral
Maximum resolution1280 x 960 pixels
Video formats supportedH.264
Analog signal format systemNTSC, PAL
White balanceAuto, Manual
Camera shutter speed1/2 - 1/10000 s
Minimum illumination5 lx
Sensor typeCMOS
Optical sensor size1/3.8 \
Video motion detectionYes
Cabling technology10/100Base-T(X)
Supported network protocolsIPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client), SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
Dimensions (WxDxH)44 x 93 x 44 mm
Networking featuresEEE802.1X
Compatible operating systemsWindowsXP, WindowsVista (32bit), Windows7 (32bit)
Power source typePoE
Power consumption (typical)2.4 W
Minimum RAM1024 MB
Compatible memory cardsSD
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 50 °C
CertificationUL2044, FCC 15B Class B, IC Class B, IEC60950-1, EN55022(B)+EN55024+EN50130-4, VCCI Class B, C-Tick Class B
Weight and Dimensions IconWeight and Dimensions
Length93 mm
Weight100 g
Diameter44 mm
