Adjusting Settings
Video Settings
You can adjust settings for video.
Lets you convert the resolution of analog video input signals and output the converted signals.
x Direct
Lets you output analog video input signals
directly.
x Auto
x 480i/576i
x 480p/576p
x 720p
x 1080i
x 1080p
z : Video signals are converted and output through the video converter.
a : The same type of signal as that of the input signal is output. Video signals are not converted.
– : Video signals are not output.
a)
The resolution is set automatically, depending on
the connected monitor.
b)
When the TV is connected to jacks other than the
HDMI jacks, 480i/576i signals are output when
“Resolution” is set to “Auto.”
Resolution (Converting video signals)
“Resolution”
menu setting
HDMI OUT
jacks
MONITOR
COMPONENT
VIDEO OUT jacks
MONITOR VIDEO
OUT jack
Direct COMPONENT VIDEO IN
jacks
– a –
VIDEO IN jacks – – a
Auto
(factory default
setting)
COMPONENT VIDEO IN
jacks
z
a)
z
b)
z
b)
VIDEO IN jacks z
b)
z
b)
480i/576i COMPONENT VIDEO IN
jacks
z
c)
zz
VIDEO IN jacks z
c)
zz
480p/576p COMPONENT VIDEO IN
jacks
zz –
VIDEO IN jacks zz a
720p, 1080i COMPONENT VIDEO IN
jacks
zz
d)
–
VIDEO IN jacks zz
d)
a
1080p COMPONENT VIDEO IN
jacks
za –
VIDEO IN jacks z – a
Input from
Output from
continued
To Next Page
