[116] Adjusting Settings Speaker Setup
Playing back WAV files stored on a USB flash drive
You can play back WAV files on a USB flash drive connected to the receiver.
This operation is only available using the display panel on the front of the receiver.
Operating the USB flash drive
You can use the following knob and buttons on the front of the receiver to operate the USB flash
drive:
MASTER VOLUME: Adjusts the volume.
ENTER: Starts or pauses playback.
/ : Press and hold to perform fast forward or fast reverse the current track.
/ : Moves to the start of the previous/current or next track.
Note
Some audio files may not be played back properly even if they are in the specified format.
[117] Adjusting Settings Network Setup
Setting up a network (Internet Setup)
You can set up a wired LAN connection by the following procedure.
If using a fixed IP address
Select [Manual] in step 3. The IP address input display appears on the TV screen.
Enter the value for [IP Address] using the on-screen keyboard. Press
/ / / and to
select the characters one by one, then select [Enter] to confirm the values.
Enter the values for [Subnet Mask], [Default Gateway], [Primary DNS] and [Secondary DNS],
then select [Next].
Hint
See [Information] when checking the network settings.
[118] Adjusting Settings Network Setup
meter: The distance is displayed in meters.
feet: The distance is displayed in feet.
Save wav files which meet the following in “/test_wav” folder on a USB flash drive.
Number of channels: 2
Sample rates (bit depth): 44.1/48 kHz (24 bit) or 44.1/48/88.2/96 kHz (16 bit)
1
Connect the USB flash drive to the SETTING
(USB) port on the front of the
receiver.
2
Press AMP MENU.
3
Select [4. AUDIO SETUP] - [4.11. PLAY TEST WAV].
Playback starts.
4
Select [Setup] - [Network Setup] from the home menu.
1
Select [Internet Setup].
2
Select [Auto].
3
Select [OK].
The receiver starts connecting to the network. For details, refer to the messages that
appear on the TV screen.
4
To Next Page
