BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A

3. 15k YPBPR SMPTE (601) Signal Adjustment

Status During Adjustment Specifications Adjustment Point

Step 1 GREEN waveform amplitude at TP1301: Use the adjustment menu Y LEVEL

. Input the 15 kHz/60 Hz YPBPR 560 ± 20 mVp-p (51H) that is located under the directory

SMPTE (601) 100% color bar signal. of the VIDEO menu of the

. Use the FORMAT item of the INPUT MAINTENANCE menu.

CONFIG menu to select YPBPR SMPTE.

Set 601 for YPBPR MATRIX.

. Connect an oscilloscope to TP1301.

Step 2 Adjust the RED waveforms to have Use the adjustment menu PR LEVEL

. Connect an oscilloscope to TP1300. the same amplitude at TP1300. (62H) that is located under the directory

Level difference: 0 ± 20 mV of the VIDEO menu of the

MAINTENANCE menu.

Step 3 Adjust the BLUE waveforms to have Use the adjustment menu PB LEVEL

. Connect an oscilloscope to TP1302 the same amplitude at TP1302. (82H) that is located under the directory

Level difference: 0 ± 20 mV of the VIDEO menu of the

MAINTENANCE menu.

Step 4 Make flat the GREEN waveform at TP1301 : Use the adjustment menu G-Y/R (71H)

. Connect an oscilloscope to TP1301. Level difference: 0 ± 20 mV and G-Y/B (91H) that is located under the

directory of the VIDEO menu of the

MAINTENANCE menu.

Adjust for the

same amplitude

Adjust for the

same amplitude

G-Y/R variable

G-Y/B variable

Make the portions flat

560±20mVp-p
