BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
Section 9
Electrical Parts List
* A-1136-024-A B COMPL
*********
7-682-947-01 SCREW +PSW 3X6
<CAPACITOR>
C300 1-163-031-11 CERAMIC CHIP0.01µF 50V
C301 1-163-031-11 CERAMIC CHIP0.01µF 50V
C304 1-104-760-11 CERAMIC CHIP0.047µF 10% 50V
C305 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C306 1-163-031-11 CERAMIC CHIP0.01µF 50V
C307 1-164-505-11 CERAMIC CHIP2.2µF 16V
C308 1-115-152-11 ELECT CHIP 22µF 20% 6.3V
C309 1-163-031-11 CERAMIC CHIP0.01µF 50V
C310 1-163-031-11 CERAMIC CHIP0.01µF 50V
C311 1-163-031-11 CERAMIC CHIP0.01µF 50V
C312 1-126-390-11 ELECT CHIP 22µF 20% 6.3V
C332 1-104-760-11 CERAMIC CHIP0.047µF 10% 50V
C333 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C334 1-163-031-11 CERAMIC CHIP0.01µF 50V
C335 1-164-505-11 CERAMIC CHIP2.2µF 16V
C336 1-163-031-11 CERAMIC CHIP0.01µF 50V
C337 1-163-031-11 CERAMIC CHIP0.01µF 50V
C338 1-115-152-11 ELECT CHIP 22µF 20% 6.3V
C339 1-164-505-11 CERAMIC CHIP2.2µF 16V
C340 1-163-031-11 CERAMIC CHIP0.01µF 50V
C341 1-163-031-11 CERAMIC CHIP0.01µF 50V
C367 1-104-760-11 CERAMIC CHIP0.047µF 10% 50V
C368 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C369 1-163-031-11 CERAMIC CHIP0.01µF 50V
C370 1-164-505-11 CERAMIC CHIP2.2µF 16V
C371 1-163-031-11 CERAMIC CHIP0.01µF 50V
C372 1-163-031-11 CERAMIC CHIP0.01µF 50V
C373 1-115-152-11 ELECT CHIP 22µF 20% 6.3V
C374 1-164-505-11 CERAMIC CHIP2.2µF 16V
C375 1-163-031-11 CERAMIC CHIP0.01µF 50V
C376 1-163-031-11 CERAMIC CHIP0.01µF 50V
C377 1-126-396-11 ELECT CHIP 47µF 20% 16V
C378 1-126-396-11 ELECT CHIP 47µF 20% 16V
C386 1-126-916-11 ELECT 1000µF 20% 6.3V
C387 1-126-916-11 ELECT 1000µF 20% 6.3V
C450 1-126-394-11 ELECT CHIP 10µF 20% 16V
C451 1-163-031-11 CERAMIC CHIP0.01µF 50V
C452 1-163-031-11 CERAMIC CHIP0.01µF 50V
C454 1-126-396-11 ELECT CHIP 47µF 20% 16V
C460 1-126-390-11 ELECT CHIP 22µF 20% 6.3V
C461 1-126-390-11 ELECT CHIP 22µF 20% 6.3V
C462 1-163-031-11 CERAMIC CHIP0.01µF 50V
C463 1-163-031-11 CERAMIC CHIP0.01µF 50V
C464 1-163-031-11 CERAMIC CHIP0.01µF 50V
C465 1-126-394-11 ELECT CHIP 10µF 20% 16V
C466 1-126-394-11 ELECT CHIP 10µF 20% 16V
C467 1-163-031-11 CERAMIC CHIP0.01µF 50V
C468 1-163-031-11 CERAMIC CHIP0.01µF 50V
C485 1-126-390-11 ELECT CHIP 22µF 20% 6.3V
C486 1-126-390-11 ELECT CHIP 22µF 20% 6.3V
C487 1-163-031-11 CERAMIC CHIP0.01µF 50V
C488 1-163-031-11 CERAMIC CHIP0.01µF 50V
C489 1-163-031-11 CERAMIC CHIP0.01µF 50V
C490 1-126-394-11 ELECT CHIP 10µF 20% 16V
C491 1-163-031-11 CERAMIC CHIP0.01µF 50V
C492 1-163-031-11 CERAMIC CHIP0.01µF 50V
C494 1-126-396-11 ELECT CHIP 47µF 20% 16V
C1300 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1301 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1302 1-163-227-91 CERAMIC CHIP10PF 0.5PF 50V
C1304 1-104-760-11 CERAMIC CHIP0.047µF 10% 50V
C1305 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1306 1-109-982-11 CERAMIC CHIP1µF 10% 10V
C1307 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1308 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1309 1-164-505-11 CERAMIC CHIP2.2µF 16V
C1320 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1321 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1322 1-163-227-91 CERAMIC CHIP10PF 0.5PF 50V
C1324 1-104-760-11 CERAMIC CHIP0.047µF 10% 50V
C1325 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1326 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1327 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1330 1-164-346-91 CERAMIC CHIP1µF 16V
C1340 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1341 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1342 1-163-227-91 CERAMIC CHIP10PF 0.5PF 50V
C1344 1-104-760-11 CERAMIC CHIP0.047µF 10% 50V
C1345 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1346 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1347 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1348 1-163-251-11 CERAMIC CHIP100PF 5% 50V
B
NOTE :
• Items marked “ * ” are not stocked since they are seldom required
for routine service. Some delay should be anticipated when ordering
these items.
• Due to standardization, replacements in the parts list may be
different from the parts specified in the diagrams or the components
used on the set.
RESISTORS
• All resistors are in ohms.
• F: nonflammable
• METAL: Metal-film resistor
• METAL OXIDE: Metal oxide-film resistor
The components identified marked ! are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque !
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
