157
DME wipe execution mode and supported pattern numbers
There are three DME wipe execution modes, depending on
the number of DME channels available: 1-channel mode
(1ch), 2-channel mode (2ch), and 3-channel mode (3ch).
The supported channel modes and pattern numbers
supported in each pattern group are shown in the following
table.
For details about pattern images (excluding user
programmable DME), see “DME Wipe Pattern List”
(page 497) and “Resizer DME Wipe Pattern List”
(page 502).
Yes: Available, No: Not available
User Program (user programmable DME) Executes a DME wipe using a DME keyframe effect created with a keyframe
operation.
For details about creating keyframe effects, see “Creating User Programmable DME
Patterns” (page 167).
Resizer Slide Executes a Slide DME wipe using a resizer.
Resizer Squeeze Executes a Squeeze DME wipe using a resizer.
Resizer Frame I/O Executes a Frame I/O DME wipe using a resizer.
Pattern group Effect
Pattern group Execution
mode
Pattern number DME wipes for common
transitions
DME wipes for
independent key
transitions
Background Key
Slide 1ch 1001 to 1008 Yes Yes Yes
2ch 2601 to 2608 Yes No No
Squeeze 1ch 1021 to 1033 Yes Yes Yes
2ch 2621 to 2628 Yes No No
Split 1ch 1011 to 1013 Yes Yes Yes
Door 1ch 1041 to 1048 Yes Yes Yes
Flip Tumble 1ch 1101 to 1104, 1109, 1110, 1121,
1122, 1124, 1131 to 1133, 1135
Ye s N o N o
Mirror 1ch 1355 to 1358 Yes Yes Yes
Sphere 1ch 1365 Yes Yes Yes
Character Trail 1ch 1371, 1372 Yes Yes Yes
Wave 1ch 1378, 1379 Yes Yes Yes
Ripple 1ch 1381 Yes Yes Yes
Page Turn 1ch 1301 to 1313, 1315 to 1318, 1341 to
1345
Ye s Ye s Ye s
2ch 2701 to 2713, 2715 to 2718, 2741 to
2745
Ye s Ye s Ye s
Roll 1ch 1321 to 1333, 1335 to 1338, 1346 to
1350
Ye s Ye s Ye s
2ch 2721 to 2733, 2735 to 2738, 2746 to
2750
Ye s Ye s Ye s
Frame I/O 1ch 1201 to 1209, 1221 to 1225 Yes Yes Yes
2ch 2851 to 2854, 2861 to 2864 Yes No No
P in P 1ch 1251 Yes No No
2ch 2651, 2652 Yes No No
2D Trans 1ch 1051 to 1058, 1061 to 1064, 1068 Yes Yes Yes
To Next Page
