3-4
122994-513 Operator Manual Component Identification
3.3 Load Side Control
Panel
The load side control panel is used to direct all washer functions.
The operator may select and review cycles and treatments, start,
stop or reset cycle operation and monitor cycle performance and
washer status from the control panel.
Standard load side control panel includes a printer.
3.3.1 Display Screen The two-line, alphanumeric screen displays cycle program data on
demand, in-cycle performance data and operator instructions. Dis-
play screen also indicates certain abnormal conditions that may
occur during a cycle (see Figure 3-2).
3.3.2 Touch Pads Cycle Status Touch Pads (see Figure 3-2):
CYCLE MENU touch pad – press to view Cycle menus. Three Cycle
menus are available.
SELECT CYCLE touch pad – press to select one of the four cycles
available from each Cycle menu.
NOTE: When a displayed cycle or treatment value is selected, cor-
responding word or digit flashes.
REVIEW CYCLE touch pad – press to review different treatments
and values programmed for selected cycle. Only those treatment
values that can be modified by operator are displayed. Refer to S
EC-
TION 4, OPERATING INSTRUCTIONS, for instructions on reviewing cycle
values.
CYCLE/START touch pad – press once to display name of selected
cycle. Press a second time to start the cycle. Refer to S
ECTION 4,
O
PERATING INSTRUCTIONS, for instructions on running a cycle.
NOTE: Selected cycle name remains on screen for five seconds after
pressing CYCLE/START touch pad once. To start a cycle, CYCLE/
START touch pad must be pressed a second time while the selected
cycle name is displayed. If touch pad is not pressed within the five
seconds, screen automatically returns to Cycle menu.
STOP/RESET touch pad – press once to stop operation of a cycle.
Press a second time to abort cycle operation. Refer to S
ECTION 4,
O
PERATING INSTRUCTIONS, for instructions on how to stop and abort
cycle operation.
NOTE: When cycle is stopped, press CYCLE/START touch pad once
to resume cycle operation. Cycle operation resumes at the point
where treatment was interrupted. When cycle is aborted, cycle opera-
tion is discontinued and cycle must be restarted from the beginning of
the cycle.
