5-20
122994-513 Operator Manual Cycle and Control Value Programming
5.8 Changing
Miscellaneous Values
EXIT function of Change Values mode is used to program various
operating values and enable/disable optional features and access
code.
Following procedure and flowchart (see Figure 5-7) show the com-
plete sequence of miscellaneous values display screens.
1. Set POWER-OFF/STANDBY switch, located behind printer
door, to POWER. Unit name temporarily appears on screen,
then screen displays first Cycle menu:
__ indicates flashing position
NOTE: When changing a cycle, note the following:
1) Change Values mode may be exited at any time by pressing
SAVE VALUES touch pad. New value entries must be con-
firmed by pressing CHANGE VALUES touch pad. Control
saves confirmed values and returns screen to selected Cycle
menu.
2) If access code feature is enabled and selected cycle is
locked out, access code sequence (see Figure 5-10) appears
after CHANGE VALUES is pressed.
2. Press CHANGE VALUES touch pad to access Change Values
mode. Printer records:
*CHANGE VALUE 8:44:51A
...and display shows:
NOTE: Pressing SAVE VALUES touch pad erases the selected
cycle from control memory. Cycle reverts to a numbered
unprogrammed listing on Cycle menu.
3. Press CHANGE VALUES touch pad. Change Cycle Name
screen appears:
__ indicates flashing position
4. Press CHANGE VALUES touch pad. Change Values screen
appears:
__ indicates flashing position
LIGHT
MEDIUM
HEAVY CYCLE 4
CVTP = MODIFY CYCLE
SVTP = ERASE CYCLE
CHANGE CYCLE NAME
L
IGHT
MODIFY
ADD
REMOVE EXIT
