STIEBEL ELTRON DCE 11/13 User Manual

32 |DCE 11/13| DCE 11/13 RC| DCE 11/13 H www.stiebel-eltron.com
INSTALLATION
Specication
Ideal temperature of approx. 38°C for hand-washing etc.
Amount of mixed water
Appliance kW 11 13.5
Cold water inlet temperature
6°C l/min 5.0 6.1
10°C l/min 5.7 6.9
14°C l/min 6.6 8.1
Values in the table are relative to a rated voltage of 400 V. The
mixed water volume and outlet volume are subject to the available
supply pressure and the available mains voltage.
16.4 Pressure drop
Taps
Pressure drop at flow rate 10l/min
Mono lever mixer tap, ap-
prox.
MPa 0.04 - 0.08
Thermostatic valve, approx. MPa 0.03 - 0.05
Hand shower, approx. MPa 0.03 - 0.15
Sizing the pipework
When calculating the size of the pipework, a pressure drop for the
appliance of 0.1MPa should be taken into account.
16.5 Fault conditions
In the event of a fault, loads up to a maximum of 80 °C at a pres-
sure of 1.0MPa can occur temporarily in the installation.
16.6 Country-specific approvals and certifications
Test symbols can be seen on the type plate.
16.7 Details on energy consumption
The product data complies with EU regulations relating to the
Directive on the ecological design of energy related products (ErP).
DCE 11/13 DCE 11/13 RC DCE 11/13 H
230770 230771 232792
Manufacturer STIEBEL ELTRON STIEBEL ELTRON STIEBEL ELTRON
Load profile XS XS XS
Energy efficiency class A A A
Annual power consumption kWh 465 465 465
Energy conversion efficiency % 40 40 40
Default temperature setting °C 60 60 60
Sound power level dB(A) 15 15 15
Special information on measuring efficiency Data at Pmax. Data at Pmax. Data at Pmax.
