STIEBEL ELTRON DCE 11/13 User Manual

ENGLISH
www.stiebel-eltron.com DCE 11/13| DCE 11/13 RC| DCE 11/13 H | 33
INSTALLATION
Specication
16.8 Data table
DCE 11/13 DCE 11/13 compact RC DCE 11/13 H
230770 230771 232792
Electrical details
Rated voltage V 380 400 415 380 400 415 380 400 415
Rated output kW 10/12,1 11/13,5 11,8/14,5 10/12,1 11/13,5 16,8/20,2 10/12,1 11/13,5 11,8/14,5
Rated current A 15,4/18,5 16,2/19,5 16,8/20,2 15,4/18,5 16,2/19,5 16,4/20,1 15,4/18,5 16,2/19,5 16,8/20,2
MCB/fuse rating A 16/20 16/20 16/20 16/20 16/20 16/20 16/20 16/20 16/20
Phases 3/PE 3/PE 3/PE
Frequency Hz 50/60 50/60 50/- 50/60 50/60 50/- 50/60 50/60 50/-
Specific resistance ρ
15
≥ (at ϑcold ≤25°C) Ω cm 900 900 900 900 900 900 900 900 900
Specific resistance σ
15
≤ (at ϑcold ≤25°C) μS/cm 1111 1111 1111 1111 1111 1111 1111 1111 1111
Specific resistance ρ
15
≥ (at ϑcold ≤55°C) Ω cm 1100 1100 1100 1100 1100 1100 1100 1100 1100
Specific conductivity σ
15
≤ (at ϑcold ≤55°C) μS/cm 909 909 909 909 909 909 909 909 909
Max. mains impedance at 50Hz Ω 0,28 0,26 0,24 0,28 0,26 0,24 0,28 0,26 0,24
Electronic standby W < 2 < 2 < 2
Connections
Water connection G 3/8 A G 3/8 A G 1/2 A
Application limits
Max. permissible pressure MPa 1 1 1
Max. inlet temperature for reheating °C 55 55 55
Values
Max. permissible inlet temperature °C 70 70 70
ON l/min >2,5 >2,5 >2,5
Flow rate for pressure drop l/min 4 4 4
Pressure drop at flow rate MPa 0,06 0,06 0,07
Pressure drop at flow rate without flow limiter MPa 0,015 0,015 0,025
Flow rate limit at l/min 4 4 4
DHW delivery l/min 3,7/4,5 3,7/4,5 3,7/4,5
Δϑ at DHW delivery K 43 43 43
Hydraulic data
Rated capacity l 0,2 0,2 0,2
Versions
Undersink installation X X
Oversink installation X
Connected load options X X X
Temperature adjustment °C 20-60 20-60 20-60
Protection class 1 1 1
Insulation block Plastic Plastic Plastic
Heating system heat generator Bare wire Bare wire Bare wire
Cap and back panel Plastic Plastic Plastic
IP-Rating IP24 IP24 IP24
Colour white white white
Dimensions
Height mm 293 293 293
Width mm 188 188 188
Depth mm 99 85 99
Weights
Weight kg 2,5 2,5 2,5
