22
User’s manual
EN
5. Delimit any areas below the surface level
of the lawn (pools, areas with signi cant
drops, stairs, etc.) (see the gure).
Carefully respect the distances in
order to prevent the robot from falling
and breaking and/or being irreversibly
damaged. Increase the distance by
at least 30 cm / 11.81 inches in the
presence of slopes or slippery ground.
6. Delimit the perimeters as shown in the
gure.
- With paths at the same height as the lawn:
5 cm (1,96 inc.)
- With paths higher than the lawn:
35 cm (13,78 inc.)
– In the presence of an enclosing wall:
35 cm (13,78 inc.)
Footpaths (at the same level as the
lawn) for allowing the robot to pass from
one area to another do not need to be
delimited.
70 cm
27,56 inc.
70 cm
27,56 inc.
5 cm
1,97 inc.
35 cm
13,78 inc.
35 cm
13,78 inc.
INSTALLATION OF THE PERIMETER WIRE
The perimeter wire can be buried or laid on
the ground.
Start laying the perimeter wire from the
installation area of the charging station
and leave a couple of meters for cutting it
down to size when connecting to the unit.
Max.
5 cm (1,96inc.)
perimeter wire
