44
User’s manual
EN
PASSWORD ENTRY
The robot can be protected by a password consisting of four numbers, which can be enabled,
disabled and personalised by the user (see “Programming Mode”).
1. On the display appears the message:
PASSWORD
0 0 0 0
2. Press either the “+” or “-” key to set the
rst number.
3. Press “Enter” to con rm. The cursor moves
to the next position.
4. Repeat the procedure to set all the numbers
of the password.
At this point, the robot is ready for use.
3
2
1
PASSWORD
0 0 0 0
VISUALISING THE DISPLAY DURING THE WORK PHASE
While in operation, the following data appears
on the display of the robot:
– left wheel motor speed
– blade motor speed
– right wheel motor spee
– battery voltage
While the robot is charging, the word
“CHARGING” appears on the display.
If the robot is outside the working time, the
display shows the day and time of the next
scheduled start.
Sx=00 La=00 Dx=00
BATTERY 0000
