9
User’s manual
EN
TECHNICAL SPECIFICATIONS
Description
Model
9L3EL
9L3LL
Maximum recommended surface that can be mowed
Robot equipped with one
13.8Ah lithium battery
m2 (sq ft)
3500
(37660)
4000
(43040)
Robot equipped with one
13.8Ah lithium battery and
two 6.9Ah lithium batteries
m2 (sq ft)
5000
(53800)
6000
(64560)
Characteristics
Size (W x H x D) mm (in.) 670 x 294 x 488 (26,8 x 11,57 x 19,21 in.)
Robot weight (incl. battery) kg
17,2
(1x13Ah Lithium)
19,2 (1x13,8Ah+2x6,9Ah Lithium)
Cutting height (Min-Max)
mm (in.) 24-64 (0,95-2,52 in)
Diameter of blade with 4
cutting edges
mm
(in.)
360
(14,17 in)
Electric motors V
cc (25.2V) with
brushes
cc (25.2V) without
brushes
Cutting blade speed
RPM
4000 Cut
3000 Maintenance
Ground speed
Metres/
Minute
30
(98 ft.)
Maximum slope
Recommended
%
45%. Allowable, based on the lawn conditions
and accessories installed.
35% Maximum recommended, in conditions of a
trimmed lawn.
20%. Next to the outside edge or guide wire.
Ambient operating
temperature
Max°
ROBOT
-10°(14 F.) (Min) +50° (122 f.) (Max)
BATTERY CHARGER
-10°(14 F.) (Min) +40° (104 f.) (Max)
Measured noise level dB(A) 80 (Max) - 65 (lawn maintenance)
Water protection class IP
IP21
Electrical features
Power Supply unit
(for lithium battery)
Class 1(Vin 90 - 295Vac 47/63Hz )
AC current (typ.) 2A/115Vac 1 A/230Vac
Battery type and charger
Rechargeable battery
Lithium-Ion
V-A
25,2V - 1x13,8Ah
25,2V - 1x13,8Ah + 2x6,9Ah
Battery charger
V-A 29,3 Vcc - 5,0 Ah
