Super X11SCL-IF User's Manual
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1, JPL2 LAN1, LAN2 Enable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JWD1 Watchdog Timer Pins 1-2 (Reset)
LED Description Status
LED2 BMC Heartbeat LED Blinking Green: BMC Normal
LED3 Onboard Power LED Solid Green: Power On
LED4 Unit Identier (UID) LED Solid Blue: Unit Identied
LED5 CATERR LED Solid Orange: System CATERR
Connector Description
B1 Onboard Battery
COM1 COM Port
FAN1 ~ FAN3, FANA CPU/System Fan Headers
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA3
Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
I-SATA2 and I-SATA3 supports SuperDOM
I-SGPIO1 Serial Link General Purpose I/O Header
JD1
Speaker Header
(Pins 1-4: Speaker; Pins 3-4: Onboard Buzzer)
JF1 Front Control Panel Header
JL1 Chassis Intrusion Header
JLED1 3-pin Power LED Header
JPW1 24-pin ATX Power Supply Connector
JPW2 4-pin Power Connector
JSD1, JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Header
JUIDB1 Unit Identier (UID) Switch
LAN1/2 1GbE LAN Ports
M.2-H
M.2 Slot for PCI-E 3.0 x4 or SATA 3.0
(Supports M-Key 2280 and Intel Optane Memory)
MH5 M.2 Mounting Hole
SLOT1 CPU PCI-E 3.0 x16 Slot
Notes: The table above is continued on the next page.
