Chapter 2: Installation
2.4 Memory Support and Installation
Note: Check the Supermicro website for recommended memory modules. Exercise
extreme care when installing or removing DIMM modules to prevent any damage.
Memory Support
The X11SCL-IF supports up to 32GB of unbuffered (UDIMM) DDR4 (288-pin) ECC memory
(1-DIMM per channel) with speeds of up to 2666MHz in two memory slots. Refer to the tables
below for the recommended DIMM population order and additional memory information.
1 CPU, 2-DIMM Slots
Number of DIMMs Memory Population Sequence
1 DIMMB1
2 DIMMB1 / DIMMA1
DIMM Type
Ranks Per DIMM
and Data Width
DIMM Capacity
(GB)
Speed (MT/s), Voltage (V),
Slot Per Channel (SPC),
and DIMM Per Channel (DPC)
1 Slot Per Channel
DRAM Density 1DPC
4GB 8GB 1.2V
Unbuffered
DDR4 ECC
SR
8GB
(2x 4GB DIMMs)
16GB
(2x 8GB DIMMs)
2666
DR
16GB
(2x 8GB DIMMs)
32GB
(2x 16GB DIMMs)

Supermicro X11SCL-IF Specifications

General

PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
ECC	Yes
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2667 MHz
UEFI version	2.7
Thermal Design Power (TDP)	95 W
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
BIOS type	UEFI
ACPI version	6.0
BIOS memory size	256 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
Wi-Fi	No
LAN controller	Intel I210
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Pentium, Intel Xeon
Processor number of cores supported	6
Component for	Server
Motherboard chipset	Intel C242
PC health monitoring	FAN, LED, Temperature, Voltage
Motherboard form factor	mini ITX
Number of SATA III connectors	4
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170.2 mm
