Supermicro X11SSH-F User Manual

Chapter 4: BIOS
101
The following IPMI information will be displayed:
• IPMI Firmware Revision
• IPMI Status
System Event Log
Enabling/Disabling Options
SEL Components
Select Enabled to enable all system event logging support at bootup. The options are Enabled
and Disabled.
Erasing Settings
Erase SEL
Select Yes, On next reset to erase all system event logs upon next system reboot. Select
Yes, On every reset to erase all system event logs upon each system reboot. Select No to
keep all system event logs after each system reboot. The options are No, Yes, On next reset,
and Yes, On every reset.
When SEL is Full
This feature allows the user to determine what the AMI BIOS should do when the system
event log is full. Select Erase Immediately to erase all events in the log when the system
event log is full. The options are Do Nothing and Erase Immediately.
Note: After making changes on a setting, be sure to reboot the system for the changes
to take effect.
BMC Network Conguration
The following items will be displayed:
• IPMI LAN Selection
• IPMI Network Link Status
Update IPMI LAN Conguration
Select Yes for the system BIOS to automatically reset the following IPMI settings upon next
system boot. The options are Yes and No.

Supermicro X11SSH-F Specifications

General

IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Maximum UDIMM memory	64 GB
Number of DIMM slots	4
Supported DIMM module capacities	4GB, 8GB, 16GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	1600, 1866, 2133 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	16 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2400
Processor socket	LGA 1151 (Socket H4)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor thermal power (max)	80 W
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Number of SATA III connectors	8
Trusted Platform Module (TPM) version	1.2
Motherboard chipset	Intel® C236
Motherboard form factor	micro ATX

Weight and Dimensions

Width	224 mm
