38 AN650A/K7 (’07-MODEL)
CONROD + CRANKSHAFT
Unit: mm (in)
OIL PUMP
ITEM STANDARD LIMIT
Piston ring thickness
1st
0.97 – 0.99
(0.038 – 0.039)
—
2nd
0.97 – 0.99
(0.038 – 0.039)
—
Piston pin bore 16.002 – 16.008
(0.6300 – 0.6302)
16.030
(0.6311)
Piston pin O.D. 15.995 – 16.000
(0.6297 – 0.6299)
15.980
(0.6291)
ITEM STANDARD LIMIT
Conrod small end I.D. 16.010 – 16.018
(0.6303 – 0.6306)
16.040
(0.6315)
Conrod big end side clearance 0.10 – 0.20
(0.004 – 0.008)
0.30
(0.012)
Conrod big end width 19.950 – 20.000
(0.7854 – 0.7874)
—
Crank pin width 20.100 – 20.150
(0.7913 – 0.7933)
—
Conrod big end oil clearance 0.032 – 0.056
(0.0013 – 0.0022)
0.080
(0.0031)
Crank pin O.D. 44.976 – 45.000
(1.7707 – 1.7717)
—
Crankshaft journal oil clearance 0.018 – 0.045
(0.0007 – 0.0018)
0.080
(0.0031)
Crankshaft journal O.D. 47.985 – 48.000
(1.8892 – 1.8898)
—
Crankshaft thrust bearing thickness 2.025 – 2.175
(0.0797 – 0.0856)
—
Crankshaft thrust clearance 0.10 – 0.15
(0.0039 – 0.0059)
—
Crankshaft runout
—
0.05
(0.002)
ITEM STANDARD LIMIT
Oil pressure (at 60 °C, 140 °F) Above 350 kPa (3.5 kgf/cm
2
, 49.8 psi)
Below 550 kPa (5.5 kgf/cm
2
, 78.2 psi)
at 3 000 r/min
—
