40 AN650A/K7 (’07-MODEL)
THROTTLE BODY
THERMOSTAT + RADIATOR + FAN + COOLANT
ITEM SPECIFICATION NOTE
TO sensor resistance 19.1 – 19.7 kΩ
TO sensor output voltage
Normal 0.4 – 1.4 V
+: Gr/R
-: B/Br
Leaning 3.7 – 4.4 V
+: Gr/R
-: B/Br
Ignition coil primary peak voltage
More than 80 V (When cranking)
#1
+: W/Bl
-: Ground
#2
+: B/Y
-: Ground
HO2 sensor heater resistance
* Approx. 13 Ω at 20 °C (68 °F)
HO2 sensor output voltage Idle speed
* 0 – 1.0 V
5 000 r/min
* 0 – 1.0 V
PAIR solenoid valve resistance 20 – 24 Ω at 20 °C (68 °F)
CVT primary pulley position sensor Compressed 1.9 – 2.3 kΩ
Extended 0.2 – 1.0 kΩ
CVT primary pulley position sensor
output voltage
1
st
: Idle speed Approx. 3.3 V
3
rd
: 3 000 r/min Approx. 1.3 V
5
th
: 3 000 r/min Approx. 0.5 V
CVT secondary pulley revolution
sensor resistance
400 – 600 Ω
CVT secondary pulley revolution
sensor peak voltage
More than 5 V at idle speed
+: Y,
-: W
ITEM SPECIFICATION
I.D. No.
* 10G2
Bore size 32 mm (1.26 in)
Fast idle r/min
* 1 200 – 1 600 r/min
Idle r/min 1 200 ± 100 r/min
ISC valve resistance
* Approx. 80 Ω at 25 °C (77 °F)
Throttle cable play 2.0 – 4.0 mm
(0.08 – 0.16 in)
ITEM STANDARD/SPECIFICATION LIMIT
Thermostat valve opening temper-
ature
Approx. 88 °C (190 °F) —
Thermostat valve lift Over 8.0 mm (0.3 in) at 100 °C (212 °F) —
Engine coolant temperature sensor
resistance
20 °C (68 °F) Approx. 2.45 kΩ —
50 °C (122 °F) Approx. 0.811 kΩ —
80 °C (176 °F) Approx. 0.318 kΩ —
110 °C (230 °F) Approx. 0.142 kΩ —
Radiator cap valve opening pres-
sure
110 kPa (1.1 kgf/cm²) —
Eclectic fan thermo-switch operat-
ing temperature
ON 93 – 103 °C (199 – 217 °F) —
OFF 87 – 97 °C (188 – 206 °F) —
