8-70 CHASSIS
• Place a clean rag underneath the union bolt 2 on the master
cylinder to catch spilled drops of brake fluid.
• Remove the union bolt 2 and disconnect the brake hose.
• Loosen the lock-nut 3.
• Remove the master cylinder mounting bolts 4.
• Remove the master cylinder along with the reservoir by turn-
ing the push rod 5.
• Remove the reservoir tank 6 and reservoir hose 7.
• Remove the connector 8 by removing the snap ring 9.
• Remove the O-ring 0.
 09900-06108: Snap ring pliers (Close type)
• Pull out the dust boot A and remove the snap ring B.
 09900-06108: Snap ring pliers (Close type)
Spilled brake fluid can damage painted surfaces and
plastic parts.
Be careful not to spill any fluid. Wipe spilled fluid up
immediately.

Suzuki GW250 Specifications

General

Engine Type	4-stroke, 2-cylinder, liquid-cooled, SOHC
Displacement	248 cc
Bore x Stroke	53.5 mm x 55.2 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Front Tire	110/80-17M/C 57H, tubeless
Rear Tire	140/70-17M/C 66H, tubeless
Curb Mass	183 kg (403 lbs)
Front Brakes	Single disc
Rear Brakes	Single disc
Fuel Tank Capacity	13.3 liters
Overall Width	760 mm
Overall Height	1, 075 mm
Wheelbase	1, 430 mm
Ground Clearance	165 mm (6.5 in)
Seat Height	780 mm (30.7 in)
Overall Length	2, 145mm (84.4 inches)
