SERVICING INFORMATION 10-47
Front brake master cylinder holder bolt 10 1.0 7.0
Front brake caliper mounting bolt 26 2.6 19.0
Front brake caliper sliding pin A 23 2.3 16.5
Front brake caliper sliding pin B 13 1.3 9.5
Front brake pad mounting pin 18 1.8 13.0
Front brake pad pin plug 2.5 0.25 2.0
Brake hose union bolt 23 2.3 16.5
Front brake lever pivot bolt 1 0.1 0.5
Front brake lever pivot bolt lock-nut 6 0.6 4.5
Air bleeder valve (Front and Rear brake caliper) 6 0.6 4.5
Brake disc bolt (Front) 18 1.8 13.0
Brake disc bolt (Rear) 23 2.3 16.5
Rear brake caliper mounting bolt 23 2.3 16.5
Rear brake caliper sliding pin 27 2.7 19.5
Rear brake pad mounting pin 18 1.8 13.0
Rear brake pad pin plug 2.5 0.25 2.0
Rear brake master cylinder mounting bolt 10 1.0 7.0
Rear brake master cylinder rod lock-nut 18 1.8 13.0
Front footrest bracket mounting bolt 23 2.3 16.5
Swingarm pivot nut 65 6.5 47.0
Rear shock absorber mounting nut (Upper) 50 5.0 36.0
Rear shock absorber mounting nut (Lower) 84 8.4 61.0
Rear axle nut 65 6.5 47.0
Rear sprocket nut 49 4.9 35.5
Side-stand nut 40 4.0 29.0
Side-stand bolt 10 1.0 7.0
Frame down tube bolt/nut 50 5.0 36.0
Rear turn signal light mounting nut 7 0.7 5.0
Front reflector bolt (For P-24) 4.5 0.45 3.5
Front reflex reflector (For P-24) 1.8 0.18 1.5
Clutch lever holder bolt 10 1.0 7.0
Clutch lever pivot nut 6.5 0.65 4.5
Bank sensor bolt 18 1.8 13.0
Center stand nut (For P-12) 60 6.0 43.5

Suzuki GW250 Specifications

General

Engine Type	4-stroke, 2-cylinder, liquid-cooled, SOHC
Displacement	248 cc
Bore x Stroke	53.5 mm x 55.2 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Front Tire	110/80-17M/C 57H, tubeless
Rear Tire	140/70-17M/C 66H, tubeless
Curb Mass	183 kg (403 lbs)
Front Brakes	Single disc
Rear Brakes	Single disc
Fuel Tank Capacity	13.3 liters
Overall Width	760 mm
Overall Height	1, 075 mm
Wheelbase	1, 430 mm
Ground Clearance	165 mm (6.5 in)
Seat Height	780 mm (30.7 in)
Overall Length	2, 145mm (84.4 inches)
