9—18

50Nm 
Ø 3,3 mm
9.3.10Preparationofsegmentsandperipheryplates
Theperipheryplatesmustbemountedtogetherforpreparationofsegmentsandperipheryplates.Ifa
standardboltisinsufficientforbringingtogetherthefirstandlastperipheryplates,athreadedrodcanbe
usedasdescribedbelow.
 Positionthethreadedrodandnut.Tightenuntilanoverlapisachieved. 

 Tightentheboltintheoverlap. 

 Replacethethreadedrodwithclampbolts. 

 Tightenallboltswhichsecuretheperipheryplateinposition. 


Useatorquewrenchtotightenthebolts. 

 Anygapsbetweentheinnerandoutersegmentsaresealedwithsealant. 


9.3.11Installationandadjustmentofbrushsealing.

Usea3,3mmdrillbittodrillthrougheveryfifthhole. 

 Installthebrushsealingusingself‐tappingscrews. 

 Theouterthreadisforprotectionandmustberemovedbeforeinstallation. 

Checkthatthebrushsealingfitstightly.Thebrushsealingmustbeadjustedifthere
isanyleakage.
Makesurethatthebrushseal‐ing
isinstalledwiththeedge facingup.






Ø 3,3mm 
casing
rotor 
