 Makesurethattheupperandloweredgesofthesegmentarelocatedwithinthebentedgesof
theradialwalls.


Tapgentlywitharubbermallettoensurethatthesegmentisintherightposition. 



















9.3.7Installation,firstperipheryplate

Positionthefirstperipheryplate.Thesidewithaholemustfaceup.Seefigure A . 

Insertaboltintheholeatthetopedgeoftheperipheryplate.Seefigure A .Donottighten. 

Insertaboltinthegrooveattheloweredgeoftheperipheryplate. 

Seefigure B .Tightenthebolt. 
 Theboltsaretightenedwhentheadjacentperipheryplatehasbeeninstalled. 

A 
B 
