SystemAir SysAqua 25 Regulation Manual

English
0.0°C
0.0°C
--------
0.0°C
0.0°C
0.0 bar
--------
0.0 K
100.0%
0.0°C
0.0°C
0.0 bar
--------
45.2°C
42.3°C
0.0%
Stage 1
off
off
Coil T.
Outer air T.
------------------------------
Discharge T.
Condensing T.
Condensing P.
------------------------------
Surperheat
Exp. valve
Suction T.
Evaporating T.
Evaporating P.
------------------------------
Leaving water T.
Entering water T.
Source Fan
Source Fan
Compressor 2
Compressor 1
1/19Circuit 2
0.0°C
0.0°C
--------
0.0°C
0.0°C
0.0 bar
--------
0.0 K
100.0%
0.0°C
0.0°C
0.0 bar
--------
45.2°C
42.3°C
0.0%
Stage 1
off
off
Coil T.
Outer air T.
------------------------------
Discharge T.
Condensing T.
Condensing P.
------------------------------
Superheat
Exp. valve
Suction T.
Evaporating T.
Evaporating P.
------------------------------
Leaving water T.
Entering water T.
Source Fan
Source Fan
Compressor 2
Compressor 1
1/19Circuit 1
Heating
Cooling
Automatic
1/3
Low load
Reduced mode
On
Off
Automatic
1/5
off
0.0%
0.0%
44°C
44°C
8.0°C
8.0°C
Heating
Reduce mode
Circuit 2
Circuit 1
Supply pump
Present capacity
Load required
Current setp. heat
Heating setp.
Current setp. cool
Cooling setp.
S/W hmi
Op. mode HMI
1/11Status
Access
Services
Commissioning
Status
1/4Main Menu
Reduced
Heating
Low load
None
1/4
Heating
NC
Ecternal switch
On/Off input
1/2
Remote control configuration
20dKdT ret./sup. temp
Remote control
Circuit control
Supply pump
Source Fan
1/5Configuration
correct
Save / load
Operation hours
Deice
Outputs manual test
Configuration
Flow switch
1/6Service
Access
Services
Commissioning
Status
1/4Main Menu
16 SysAqua
3. FUNCTIONS
3.1. ON/OFF
SysAqua can be switched on and off in different ways:
² External input: The unit is
operating if the contact is closed.
Shutdown by this input has
priority
² User interface: The operation
can be started by the onboard
or online (HMI1Web) graphic
interface status menu
² GTC: the operation can be
controlled by a GTC through different communication protocols (Refer to the § COMMUNICATION,
page 11).
The shutdown sequence for the unit overrides the minimum operation time of the actuators. However, the
operation sequence takes these times into account.
The deicing sequence has priority over the request to shutdown the unit.
The external contact has priority over the other operating modes when shutting down the SysAqua.
However, if the mode is off on the user interface or GTC, the unit remains shutdown whatever the status of
the external contact.
The operating of the SysAqua through the user interface has priority over a GTC shutdown request.
3.2. OPERATING MODE
This parameter is not accessible for the "Cool only" units.
If the unit is reversible, its operating mode can be dened:
 Automatic mode
 Heat mode
 Cool mode
The current mode can be viewed on the home page of the user interface as well as by the communication
networks:
² Modbus: actual operating mode (0x0002)
² Bacnet: “Actual operating mode"
The mode can be selected either
² By the external contact: For this, the external contact must be congured in "Heating" mode.
This can be congured in the "Service" menu via the "Conguration" screen (Refer to the §
CONFIGURATION, page 12). A closed contact on this input corresponds to the heat mode, if it is
open, to the cool mode. If this contact is congured, it has priority.
² By the user
interface: Go
to the user menu and modify the operating mode on the
relevant line.
² By the GTC: The selection is made by the remote operating
mode variable
(holding register: 0x0000 in modbus)
3.2.1. GENERALITY
