Takeuchi TB290 User Manual

8-4
OPTIONS
ATTACHMENT COMBINATION TABLE
The table below shows which bucket should be installed when the machine is using a
standard arm, middle arm or long arm. Select a proper bucket by following the table.
Warning
•ConsultwithTakeuchibeforeinstallinganoptionalattachment.
•DonotuseanyattachmentsnotapprovedbyTakeuchi.Doingsomaycausesafety
problems. Or, it may adversely affect the machine’s operation or service life.
•Wewillnotbeheldresponsibleforanyinjuries,accidentsordamagetoitsproducts
caused by the use by a non-approved attachment.
•Theswingstoppermustbeinstalledwhenabucketwiderthana750W(standard)
bucket is installed. Failure to do so may result in the bucket hitting the machine body.
•Installthelightweightweightorwidewidthsteelcrawlerifthelongarmisinstalled.
√ :Can be used.
∆ :Can be used only for light operations (digging and loading of dry and loose soil or mud)
— :Cannot be used.
Totalbucketmass=Bucketmass+Heapedbucketload(specicgravity:1.8)
ATTACHMENT COMBINATION TABLE
Bucket
Rated
capacity
m
3
(cu.yd.)
Bucket
cutting width
mm (inch)
Standard arm
1780 mm
(70 in.)
Middle arm
1960 mm
(77 in.)
Long arm
2130 mm
(84 in.)
430W
(no side cutter)
0.14 (0.18) 430 (16.9) √ √ √
500 W 0.14 (0.18) 500 (19.7) √ √ √
650 W 0.20 (0.26) 650 (25.6) √ √ √
750 W
(S.T.D.)
0.25 (0.33) 750 (29.5) √ √ —
3-hole bucket 0.26 (0.34) 610 (24.0) √ — —
Total bucket weight=
Within 657 kg (1448 lb.)
Within
750 (29.5)
√ — —
Hydraulic
Breaker(TKB-401) √ — —
