Takeuchi TB290 User Manual

2-30
CONTROLS
LIGHT SWITCH
SWITCHES
When this switch is turned while the starter
switch is at ON, the lights turn on as follows:
OFF ....Off
ON .....Instrument cluster light, switch lamps,
front light, boom light, side lights and
tail lamps will be lit.
(switch lamp is lit)
OVERLOAD WARNING SWITCH
BEACON LAMP SWITCH
When this switch is turned on while the
starter switch is at ON, the lamp turns on as
follows:
OFF ....Off
ON .....Beacon lamp is lit
Warning
If the overload is not removed after the
overload warning horn is sounded, the
machine may tip over or the emergency
shut-off valve may be activated. If the
horn starts sounding, stop operating the
machine and lighten the load.
If a weight greater than the lifting capacity is
applied or lifted, the overload warning device
is activated and the horn sounds. (When the
overload warning switch is turned on.)
OFF
....Off
ON .....On
If the emergency shut-off valve is activated,
the overload warning horn stops.
(This is because the pressure sensor can no
longer detect hydraulic pressure.)
Pressing the OFF side changes to the
momentary mode.
