Takeuchi TB290 User Manual

2-32
CONTROLS
BLADE LEVER
LEVERS AND PEDALS
Use this lever to operate the dozer blade.
(A) .......Blade up
(B) ......Blade down
Refer to “Operating the dozer blade” on
page 3-15.
Machines with the float switch (USA
specification)
Warning
•Donotpresstheoatbuttonwhilethe
machine is raised by the blade. Doing
so will cause the machine to fall. If you
must work beneath the raised machine,
always use a secure support to keep the
machine raised.
•Donotpresstheoatbuttonwhilethe
blade is raised. Doing so will cause the
blade to fall. Lower the blade to the
ground before pressing the float button.
•Donottravelforwardwhilethebladeis
in the float mode.
Float operation
Button (C)
. Float mode
Press the float switch to set the
dozer blade to the float mode.
To cancel the float mode, press
the switch again.
