Display Waveform Data
4. Push Screen Annotation from the resulting
lower-bezel menu.
Utility Page
Display
Backlight
Intensity
High
Graticule
Full
Screen
Annotation
5. Push Display Anno tation to select On from
the side-bezel menu.
The anno tation window now ap pears. Position
it by turning multipurpose knobs a and b.
6. Push Edit An notation from the side-bezel
menu
7. Turn multipurpose knob a to scroll through the
list of letters, numbers, and other characters to
select each desired character.
Alternatively, use a US-style USB keyboard to
type in characters. (See page 48, Connecting
a U SB Keyboard to Your Oscilloscope.)
To reposition the annotated text, p ress
the side-bezel Position button and turn
multipurpose knobs a and b, as desired.
154 DPO3000 Series Oscilloscopes User Ma nual
