Save and Recall Information
4. Push Orientation to select between saving
the image in a landscape (horizontal) and a
portrait (vertical) orientation.
Orientation
5. Push Ink Saver to tur n the Ink Saver mode on
or off. When on, this mode p rovides a white
background.
Ink Saver
On |
Off
6. Push Edit File Name to create a custom name
for the screen image file.Skipthissteptouse
a default name.
Edit File
Name
7. Push OK Save Screen Image to write the
image to the selected media.
OK Save
Screen
For information on printing screen images of waveforms, go to PrintingaHardCopy. (See page 214, Printing a Hard Copy.)
Saving and Recalling Waveform Data
Waveform d ata consists of the numeric values for each point in t he waveform. It copies the data, as opposed to a graphical image
of th e scree n. To save the current waveform data or to recall previously stored wa veform data:
204 DPO3000 Series Oscilloscopes User Ma nual
