Brief Procedures
TDS 520A, 524A, 540A, & 544A Service Manual
4Ć3
H !
!
!
Brief Status
Information
Position of Waveform
Record Relative to
the Screen and Display
General Purpose
Knob Readout
Waveform Reference
Symbols: Ground Levels
and Waveform Sources
Graticule and
Waveforms
Side menu area.
Readouts for
measurements
move here when
CLEAR MENU is
pressed.
Main menu display area. Readouts in
lower graticule area move here when
CLEAR MENU is pressed.
PopĆup Menu
Vertical Scale,
Horizontal Scale, and
Trigger Level Readouts
Figure 4Ć1:ăMap of Display Functions
