Specifications
2–4
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Both the delayed only display and the intensified zone on the main intensified
display may be delayed by time with respect to the main trigger. Both can be set
to display immediately after the delay (delayed runs after main mode). The
delayed display can also be set to display at the first valid trigger after the delay
(delayed-triggerable modes).
The delayed display (or the intensified zone) may also be delayed by a selected
number of events. In this case, the events source is the delayed-trigger source.
The delayed trigger can also be set to occur after a number of events plus an
amount of time.
Table 2–2: Record length and divisions per record versus TDS model
Divisions per record
Standard Models Record length
FTS
1
Off
2
FTS
1
On3
All TDS 500D, TDS600C, TDS 694C,
500 10 div 10 div
TDS 700D, & TDS 714L, all channels
4
1,000 20 div 10 div
2,500 50 div 10 div
5,000 100 div 10 div
15,000 300 div 10 div
TDS 694C, all channels 30,000 600 div 15 div
TDS 500D, TDS 700D, & TDS 714L,
all channels
50,000 1,000 div 15 div
Divisions per record
Models with Option 1M
5
Record length
FTS
1
Off
2
FTS
1
On
3
TDS 694C, all channels 50,000 1,000 div 10 div
TDS 500D, TDS 694C, TDS 700D, &
TDS 714L, all channels
75,000 1,500 div 15 div
TDS 500D, TDS 694C, TDS 700D, &
TDS 714L, all channels
100,000 2,000 div 12 div
TDS 694C, all channels 120,000 2,400 div 13 div
TDS 500D, TDS 700D, TDS 714L,
all channels
130,000 2,600 div 10 div
TDS 520D, one channel only
TDS 540D, TDS 580D, all TDS 700D, &
TDS 714L, one or two channels
250,000 5,000 div 10 div
TDS 540D, TDS 580D, & all TDS 700D,
one channel only
500,000 10,000 div 10 div
