Tektronix TDS 700D Technical Reference

TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
2–11
Nominal Traits
Tables 2–3 through 2–9 list the various nominal traits that describe the
TDS 500D, TDS 600C, TDS 700D and TDS 714L Oscilloscopes. Electrical and
mechanical traits are included.
Nominal traits are described using simple statements of fact such as “Four, all
identical” for the trait “Input Channels, Number of,” rather than in terms of
limits that are performance requirements.
Table 2–3: Nominal traits — Signal acquisition system
Name Description
Bandwidth Selections 20 MHz, 250 MHz, and FULL (No BW limit on TDS 694C or TDS 794D)
Samplers, Number of TDS 540D, 580D, 654C, 684C, 694C, 714L, 754D, 784D, and 794D: Four, simultaneous
TDS 520D, 680C, and 724D: Two, simultaneous
Digitized Bits, Number of 8 bits
1
Input Channels, Number of Four
Input Coupling DC, AC, or GND (TDS 694C/794D – DC or GND only)
Input Impedance Selections
1 MW or 50 W (TDS 694C/794D – 50 W only)
Ranges, Offset Volts/Div setting Offset range
(All except TDS 694C/794D)
1 mV/div – 100 mV/div
101 mV/div – 1 V/div
1.01 V/div – 10 V/div
±1 V
±10 V
±100 V
Ranges, Offset (TDS 694C/794D only) 10 mV/div – 50 mV/div
50.5 mV/div – 100 mV/div
101 mV/div – 500 mV/div
505 mV/div – 1 V/div
±0.50 V
±0.25 V
±5 V
±2.5 V
Range, Position ±5 divisions
Range, 1 MW Sensitivity
3
1 mV/div to 10 V/div
2
Range, 50 W Sensitivity 1 mV/div to 1 V/div
2
(10 mV/div – 1V/div on TDS 694C/794D)
1
Displayed vertically with 25 digitization levels (DLs) per division and 10.24 divisions dynamic range with zoom off. A DL
is the smallest voltage level change of the oscilloscope input that can be resolved by the 8-bit A-D Converter. Expressed
as a voltage, a DL is equal to 1/25 of a division times the volts/division setting.
2
The sensitivity ranges from 1 mV/div to 10 V/div (for 1 MW) or to 1 V/div (for 50 W) in a 1–2–5 sequence of coarse settings
with Fit-to-Screen off. Between coarse settings, the sensitivity can be finely adjusted with a resolution equal to 1% of the
more sensitive coarse setting. For example, between 50 mV/div and 100 mV/div, the volts/division can be set with 0.5 mV
resolution.
3
1 MW not available on TDS 694C &TDS 794D oscilloscopes.
