Performance Tests
1–18
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Equipment Required
Procedures starting on page 1–35, use external, traceable signal sources to
directly check warranted characteristics. Table 1–1 lists the required equipment.
Table 1–1: Test equipment
Item number and
description
Minimum requirements Example Purpose
1. Attenuator,10X
(two required)
Ratio: 10X; impedance 50 W; connec-
tors: female BNC input, male BNC
output
Tektronix part number
011-0059-02
Signal Attenuation
2. Attenuator, 5X Ratio: 5X; impedance 50 W; connec-
tors: female BNC input, male BNC
output
Tektronix part number
011-0060-02
Signal Attenuation
3. Adapter, BNC female-to-
Clip Leads
BNC female-to-Clip Leads Tektronix part number
013-0076-00
Signal Coupling for Probe
Compensator Output Check
4. Terminator, 50 W Impedance 50 W; connectors: female
BNC input, male BNC output
Tektronix part number
011-0049-01
Signal Termination for
Channel Delay Test
5. Cable, Precision 50 W
Coaxial (three required)
50 W, 36 in, male-to-male BNC
connectors
Tektronix part number
012-0482-00
Signal Interconnection
6. Connector, Dual-Banana
(two required)
Female BNC-to-dual banana Tektronix part number
103-0090-00
Various Accuracy Tests
7. Connector, BNC “T” Male BNC-to-dual female BNC Tektronix part number
103-0030-00
Checking Trigger Sensitivity
8. Coupler, Dual-Input Female BNC-to-dual male BNC Tektronix part number
067-0525-02
Checking Delay Between
Channels
9. Generator, DC Calibra-
tion
Variable amplitude to ±104 V; accura-
cy to 0.1%
Data Precision 8200
1
Checking DC Offset, Gain,
and Measurement Accuracy
10. Generator, Calibration 500 mV square wave calibrator
amplitude; accuracy to 0.25%
Tegam/Tektronix PG 506A
Calibration Generator
1,3
To check accuracy of CH 3
Signal Out
11. Generator, Time Mark
(optional)
Variable marker frequency from 10 ms
to 10 ns; accuracy within 2 ppm
Tegam/Tektronix TG 501A
Time Mark Generator
1,3
Checking Sample-Rate and
Delay-time Accuracy
12. Probe, 10X A P6139A
2
, P6243, P6249, P6245, or
P6339A probe
4
Tektronix part number
P6139A or P6245
Signal Interconnection
13. 3.5 inch, 720 K or
1.44 Mbyte, DOS-com-
patible floppy disk
TDS Family Programmer Disk
(Tektronix part number
063–3120–00), included with
User Manual (Tektronix part
number 071–0130-XX)
Checking File System Basic
Functionality
14. Generator, Sine Wave 250 kHz to at least 500 MHz (higher
for higher-bandwidth scopes). Vari-
able amplitude from 60 mV to 2 V
p-p
into 50 W. Frequency error >2.0%
Rohde & Schwarz SMT or
SMY
1,5
Checking Analog Bandwidth,
Trigger Sensitivity, Sample-
rate, External Clock, and
Delay-Time Accuracy
