Tektronix TDS 700D Technical Reference

Performance Tests
1–32
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
TDS794D Test Record
Photocopy this and the next two pages and use them to record the performance
test results for your TDS794D.
TDS794D Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS794D Performance Test Minimum Incoming Outgoing Maximum
Offset Accuracy
CH1 Offset +10 mV
+101 mV
– 2.5 mV
– 25.1 mV
__________
__________
__________
__________
+ 2.5 mV
+ 25.1 mV
CH2 Offset +10 mV
+101 mV
– 2.5 mV
– 25.1 mV
__________
__________
__________
__________
+ 2.5 mV
+ 25.1 mV
CH3 Offset +10 mV
+101 mV
– 2.5 mV
– 25.1 mV
__________
__________
__________
__________
+ 2.5 mV
+ 25.1 mV
CH4 Offset +10 mV
+101 mV
– 2.5 mV
– 25.1 mV
__________
__________
__________
__________
+ 2.5 mV
+ 25.1 mV
DC Voltage Measurement Accuracy (Averaged)
CH1 10 mV Vert scale setting,
–5 Div position setting, +.5 V offset
+0.5755 V __________ __________ +0.5845 V
CH1 10 mV Vert scale setting,
+5 Div position setting, –.5 V offset
–0.5845 V __________ __________ –0.5755 V
CH1 200 mV Vert scale setting,
0 Div position setting, +5 V offset
+4.9405 V __________ __________ +5.0595 V
CH1 200 mV Vert scale setting,
0 Div position setting, –5 V offset
–5.0595 V __________ __________ –4.9405 V
CH1 1 V Vert scale setting,
0 Div position setting, +2.5 V offset
+4.794 V __________ __________ +5.206 V
CH1 1 V Vert scale setting,
0 Div position setting, –2.5 V offset
–5.206 V __________ __________ –4.794 V
CH2 10 mV Vert scale setting,
–5 Div position setting, +.5 V offset
+0.5755 V __________ __________ +0.5845 V
CH2 10 mV Vert scale setting,
+5 Div position setting, –.5 V offset
–0.5845 V __________ __________ –0.5755 V
CH2 200 mV Vert scale setting,
0 Div position setting, +5 V offset
+4.9405 V __________ __________ +5.0595 V
