TDS 500D, TDS 600B, & TDS 700D User Manual
A–1
Appendix A: Options and Accessories
This appendix describes the various options as well as the standard and optional
accessories that are available for the TDS Oscilloscope.
Options
Tektronix will ship the options shown in Table A–1:
Table A–1: Options
Option # Label Description
A1 Universal European
power cord
220 V, 50 Hz power cord
A2 UK power cord 240 V, 50 Hz power cord
A3 Australian power cord 240 V, 50 Hz power cord
A4 North American power
cord
240 V, 60 Hz power cord
A5 Switzerland power cord 220 V, 50 Hz power cord
05 Video trigger Oscilloscope comes with tools for investigating events that occur when a video signal
generates a horizontal or vertical sync pulse. These tools allow investigation of a range of
NTSC, PAL, SECAM, and high definition TV signals. (Option is not available on the
TDS 794D.)
13 RS-232/Centronics Hard-
copy Interface Ports
Add RS-232-C and Centronics interface ports.
(Option applies to TDS 500D only.)
1G 1 GS/s maximum Limit sample rate to 1 GS/s maximum.
(Option applies to TDS 540D and TDS 754D only.)
1K Scope cart K420 scope cart. This cart can help transport the oscilloscope around many lab environ-
ments.
24 Four passive probes Add four 500 MHz P6139A passive probes
(Option applies only to TDS 600B models.)
26 Four active probes Add four 1.5 GHz (probe only) P6245 active probes
(Option applies only to TDS 684B models.)
27 Two active probes Add two 1.5 GHz (probe only) P6245 active probes
(Option applies only to TDS 680B.)
