Using Frame Picture Generator
Using Frame Pi
cture Generator
The Frame Pic
ture Generator application is used only with the following modules:
AVG7 Analog Video Generator Module
AWVG7 Analog Wideband Video Generator Module
DVG7 Digital Video Generator Module
HDVG7 HDTV Digital Video Generator Module
Frame Picture Generator is a software application for a PC using the Microsoft
Windows system. Frame Picture Generator provides the capability to convert a
Windows bitmap fi le (.bmp) to a frame picture file (.pic) that can be used by the
TG8000. Using this application, you can convert a natural picture or a test pattern
in bitmap format to a frame picture file and output it as a picture.
This section provides the following information:
Installation instructions
Starting and exiting Frame Picture Generator
Elements of the Frame Picture Generator window
Using the Frame Picture Generator menus
Frame Picture Generator tutorials
Installation instructions
This subsection provides instructions to install the Frame Picture Generator
application on your PC.
Installing Frame Picture
Generator
The following installation instructions require that you are familiar with the basics
of using the Windows operating system. If necessary, read your Windows user
documentation before installing Frame Picture Generator.
Perform the following procedure to install the Frame Picture Generator:
1. Be sure that your PC meets the requirements before proceeding with the
installation. (See page viii, PC system requirements.)
2. Insert the TG8000 Multiformat Test Signal Generator SW Library and
Documentation DVD (063-4440-XX) into a DVD drive on your PC.
3. When the Product Software and Documentation Browser window appears,
select the TG7 Tools Software link.
4. Select the Frame Picture Generator link to install the software. Follow the
on-screen instructions to complete the software installation.
TG8000 Multiformat Test Signal Generator PC Tools Technical Reference 9
