UsingLogoGenerator
Using Logo Gen
erator
The Logo Gene
rator application is used only with the following modules:
DVG7 Digital Video Generator Module
HDVG7 HDTV Digital Video Generator Module
Logo Generator is a software application for a PC using the Microsoft Windows
system. Logo Generator provides the capability to convert a Windows bitmap
file (.bmp) to a logo file (.lgo) that can be used w ith the logo overlay feature of
the DVG7 or
HDVG7 module.
This section provides the following information:
Installation instructions
Starting and exiting Logo Generator
Elements of Logo Generator window
Using the Logo Generator menus
Logo G
enerator tutorials
Installation instructions
This
subsection provides instructions to install the Logo Generator application
on your PC.
Installing Logo Generator
The following installation instructions require that you are familiar with the basics
of u
sing the Windows operating system. If necessary, read your Windows user
documentation before installing Logo Generator.
Pe
rform the following procedure to install the Logo Generator software:
1. Be sure that your PC meets the requirements before proceeding with the
i
nstallation. (See page viii, PC system requirements.)
2. Insert the TG8000 Multiformat Test Signal Generator SW Library and
Documentation DVD into a DVD drive on your PC.
3. When the Product Software and Documentation Browser window appears,
select the TG7 Tools Software link.
4. Select the Logo Generator link to install the software. Follow the on-screen
instructions to complete the software installation.
TG8000 Multiformat Test Signal Generator PC Tools Technical Reference 17
