63
4.10 Example of repeater mode and P2MP mode
Network requirement
You have three offices in an estate which are not far away from each other, and only one office has
internet service. Now you want to combine the networks in three offices into one, and provide
wireless networks to wireless devices in the offices without internet service.
Solution
Set CPE1 to P2MP mode, and set CPE2 and CPE3 to Repeater mode.
Network topology
Configuration procedures
Assume that the wireless parameters of CPE1 are shown as follows:
− IP Address: 192.168.2.1
− SSID: Tenda_123456
− Channel: 165
− Security mode: None
Step 1 Configure the wireless settings of CPE2.
1. Log in to the web UI of CPE2, and choose Wireless > Basic to enter the configuration page.
2. Change the SSID, which is Tenda_1 in this example.
3. Set the Channel to the same as that of CPE1, which is 165 in this example.
4. Set the Security Mode to the same as that of CPE1, which is None in this example.
