Tenda I-WL-O3 User Manual

1
1 Application scenario
1.1 ISP hotspot connection-WISP mode
An apartment needs to bridge an ISP hotspot for internet access.
1.1.1 Solution
Tenda CPE can meet this demand.
O4 is used as an example to illustrate the installation procedures. Procedures for other CPEs are
similar.
To establish the network quickly, you are recommended to set up the CPEs before installing them.
1.1.2 Set up the CPE
Step 1 Connect the computer to the CPE.
1. Uncover the housing of the CPE.
2. Use an Ethernet cable to connect the PoE/LAN/WAN port of the device to the PoE port of
the PoE injector.
3. Use the included power adapter to connect the PoE injector to a power socket. The
LAN/WAN LED indicator of the CEP lights up.
4. Use an Ethernet cable to connect your computer to the LAN port of the PoE injector.
