Tenda W330R User Manual

Wireless-N Broadband Router
How to Check the Network Connection
Select“Start”— ”Program
s”—“Accessories”
—“Command Prompt”.
Input the “ping
192.168.0.1” and press
“Enter”. If the screen
displays as the right figure,
it means your PC is
connected to your router
successfully.
If not, please make sure
the hardware installation
and network adapter are
OK. After all preparations
are made, please proceed
to Chapter 4 for more and
advanced configuration.
9

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
