Tenda W330R User Manual

Wireless-N Broadband Router
This section deals with the
port range forwarding
mainly. The Port Range
Forwarding allows you to
set up a range of public
services such as web
servers, ftp, e-mail and
other specialized Internet
applications to an
assigned IP address on
your LAN.
Start/End Port: Enter the
start/end port number
which ranges the External
ports used to set the
server or Internet
applications.
IP Address: Enter the IP
address of the PC where
you want to set the
applications.
Protocol:Select the
protocol (TCP/UDP/Both)
54
Port Range Forwarding

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
