Tenda W330R User Manual

Wireless-N Broadband Router
WAN Settings—L2TP
L2TP Server IP: Enter the
Server IP provided by your
ISP.
User Name: Enter L2TP
username.
Password: Enter L2TP
password.
MTU: Maximum
Transmission Unit, you
may need to change it for
optimal performance with
your specific ISP. 1400 is
the default MTU.
Address Mode: Select
“Static” if your ISP
supplies you with the IP
address, subnet mask,
and gateway. In most
cases, select Dynamic.
IP Address: Enter the
L2TP IP address supplied
20

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
