Tenda W330R User Manual

Wireless-N Broadband Router
for the application.
Well-Known Service
Port: Select the well-
known services as DNS,
FTP from the drop-down
menu to add to the
configured one above.
Delete/Enable:Click to
check it for corresponding
operation.
Port Trigger Settings
When internal clients have
access to external server
in the Internet for some
application, the clients
request to connect with
severs, and the server will
also ask to connect with
client. But in the default
setting, router will refuse
to accept any request from
55

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
