Tenda W330R User Manual

Wireless-N Broadband Router
WAN Settings—PPPoE
Connection Mode:Show
your current connection
mode.
Account: Enter them
provided by your ISP.
Password: Enter them
provided by yourISP.
MTU: Maximum
Transmission Unit. It is the
size of largest datagram
that can be sent over a
network. The default value
is 1492. Do NOT modify it
unless necessary.
Service Name: It is
defined as a set of
characteristics that are
applied to a PPPoE
connection. Enter it if
provided. Do NOT modify
it unless necessary.
AC Name: Enter it if
17

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
